Features

The entire working process, from cigarettes feeding to carton overwrapping, is completed automatically without any manual contact. The settings of machine operation, quality control, shift reporting, enhanced stoppage analysis, machine status, diagnostics and system calibration are achieved entirely digitally by the brand new MICRO-II system with integrated touch screens.

Technical Data

Production Capacity:      400 packets/min (40 cartons/min)

Cigarette Specifications

Diameter                        φ7.8mm
Length                           84mm
Cigarette Collation:        7-6-7

Packet Dimension:         86mm ×54.5mm ×22.5mm

Stamp Specifications

Width:                           19mm ~23mm
Length:                         42mm~50mm

Carton Dimension:        274mm × 87.5mm × 46.5mm

(American and European style)

Noise Level:                  ≤85 dB(A)
Power:                          19.1kw
Weight:                         9370kg

Floor Area:                   7300mm × 7600mm
